Technical Data.
Model:
A1-G (Front ejection with grooved cooking plates)
A1-S (Front ejection with smooth cooking plates) |
Top Plate Height |
13/16" (20 mm) |
Adjustments: |
1 1/4" (31 mm) |
Overall Dimensions |
26"W x 18"D x 16"H
66cm x 45cm x 40cm |
Cooking Surface |
15"W x 5½"D
38cm x 14cm |
Electrical Requirements |
120V, 1500 W
13Amps, 60Hz  5-15
- OR -
208-240V, 3000W
14Amps, 50/60Hz  6-15 |
Net Weight |
33 Ibs ( 15 kg ) |
Shipping Weight |
50 lbs ( 23 kg ) |
|
Model:
A2-G (Front ejection with grooved cooking plates)
A2-S (Front ejection with smooth cooking plates) |
Top Plate Height |
1 1/16" (27 mm) |
Adjustments: |
1 3/4" (44 mm)
2 11/32" (59 mm)
2 15/16" (74 mm) |
Overall Dimensions |
24¼"W x 25¼"D x 28"H
61.6cm x 64cm x 71cm |
Cooking Surface |
15"W x 9 3/8"D
38cm x 23.8cm |
Electrical Requirements |
208-240V, 3000W
14Amps, 50/60Hz 6-15 |
Net Weight |
70 Ibs ( 32 kg ) |
Shipping Weight |
89 lbs ( 41 kg ) |

United States Design Patent Number D415923
Canadian Patent Number: 2210583
Canadian Industrial Design Patent Number 85558
British Patent Number GB2326330 and other patents pending
Information and specifications subject to change without notice.
|
